ZebbiesPels Ceiling Fan

Please Note

• Ceiling fans tend to move during operation due to the fact that they are mounted on a rubber grommet. If the fan is mounted rigidly to the ceiling it will cause excessive vibration
• When installing this ceiling fan ensure that the ceiling joist or structure is capable of carrying a load of at least 16kg
• The pairing of the remote and receiver has been done at the factory. When the ceiling fan is installed, pairing the fan receiver and remote is NOT required
• Should the remote and receiver lose control after installation or during use, the remote and the receiver must be repaired
• Always turn OFF the power at the mains switch before performing any maintenance or attempting to clean your fan

About

There are many benefits to incorporating ceiling fans into the design of your home. Using ceiling fans throughout your home greatly reduces energy costs while also providing comfort, style & beautiful lighting. We recommend you have the fan complement your features & finishes within your designed décor.

Product Features

• Dark KOA Cast Aluminium Finish and Plastic Blades
• 3 Speed Remote and Receiver Included - AAA Batteries for remote not included
• 80W AC Motor
• Suitable for Coastal Conditions
• Suitable Room Size: 6m x 6m
• 2 Year Warranty

Maintenance & Cleaning

• Every 6 months periodic cleaning of your ceiling fan is the only maintenance required. Use a soft brush or lint-free cloth to avoid scratching the paint finish Please turn off electrical power when you do so
• Do not soak or immerse your ceiling fan in the water or other liquids. It could damage the motor or the blades and create the possibility of an electrical shock
• Ensure that the fan does not come in contact with any organic solvents or cleaners
• To clean the fan blades, wipe with only a dry clean cloth with NO organic solvents or cleaners
• The motor has a permanently lubricated ball bearing so there is no need to oil

Dimensions

• Width: 1480mm
• Height with Rod: 330mm

PLEASE NOTE THE BELOW WHEN PURCHASING MORE THAN ONE REMOTE CONTROL FAN

• When two or more fans are located near each other, you may want to have the remote and the receiver for each fan set to a different code, so that the operation of one fan does not affect the operation of the other fan/s.
• Safety checks and special instructions:
• Ensure that the receiver is ON prior to pairing the remote with the receiver.

Receiver pairing for ceiling fan 1

• Turn OFF both ceiling fans at the mains supply to the receiver
• Install the 2 x 1.5 AAA batteries in the compartment. Please make sure that these have been inserted the correct way.
• Turn ON the power to receiver 1, keep the power OFF to receiver 2 (each ceiling fan must have its own switch so that the ceiling fan that needs to be paired with the receiver will be on)
• Press and hold the power button on remote 1 for 3 seconds
• Turn ON and change the speed of ceiling fan 1 by the remote to check the operation has been successful.

Receiver pairing for ceiling fan 2

• Turn OFF both ceiling fans 1 and 2 via the mains supply to the receiver
• Install the 2 x 1.5 AAA batteries in the compartment. Please make sure that the polarity of the battery is correct.
• Turn ON the power to receiver 2, keep the power OFF to receiver 1 (each ceiling fan must have its own switch so that the ceiling fan that needs to be paired with the receiver will be on)
• Press and hold the power button on transmitter 2 for 3 seconds within 60 seconds of switching the power to the receiver of ceiling fan 2
• Turn ON and change the speed of ceiling fan 1 by the transmitter to check the operation has been successful
